Ubiquiti USW-LITE-8-POE UniFi Switch USW-Lite-8-POE/4x PoE Output Ports/52W PoE Supply/Fanless/Wall Mount Kit Included
An 8-port. Layer 2 PoE switch supporting silent fanless cooling.
- (4) GbE PoE+. (4) GbE ports
- 52W total PoE availability*
- Wall mountable
*With an external 60W power adapter.
MECHANICAL
Dimensions: 99.6 x 163.7 x 31.7 mm (4 x 6.4 x 1.3')
Weight: 295 g (10.4 oz)
Enclosure material: Polycarbonate
HARDWARE
Management interface: Ethernet In-Band
Networking interface: (8) GbE RJ45 ports
PoE interface: (4) PoE/PoE+ (Pins 1. 2+; 3. 6-)
Total non-blocking throughput: 8 Gbps
Switching capacity: 16 Gbps
Power method: 54V DC. 1.1A power adapter
Power supply: 54V. external. 60W
Supported voltage range: 50—57V DC
Max. power consumption: 8W (Excluding PoE output)
Total available PoE: 52W**With an external 60W power adapter.
Max. PoE wattage per port by PSE: PoE+: 30W
Button: Factory reset
Ambient operating temperature: -15 to 40° C (5 to 104° F)
Ambient operating humidity: 10 to 90% noncondensing
Certifications: CE. FCC. IC
SWITCHING FEATURES
Layer 2 features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
LEDs
System: Status
Ethernet: PoE Speed/link/activity
PoE: Link/activity
APPLICATION REQUIREMENTS
UniFi Network: Version 7.2.94 and later
